16 ports VoIP GSM Gateway /  VoIP GSM/UMTS Gateway / 4G LTE Gateway (from 16 to 32 GSM channels)

MV-3716 is a 16 channels VoIP GSM/UMTS/LTE Gateway for call termination (VoIP to GSM/UMTS/LTE  ) and origination ( GSM/UMTS/LTE  to VoIP). It is SIP based and compatible with Asterisk,Trixbox,3CX,SIP Proxy Server,VoipBuster. It can enable to make 16 calls simultaneously from IP phones to GSM/UMTS/LTE  networks and GSM/UMTS/LTE  networks to IP phone.

Catalog       User manual     MV-37X works with Elastix

Function:

• VoIP(SIP)- GSM/UMTS/LTE  Conversion
• Support LCR(Least Cost Routing) for cost reduction
• SMS receiving and sending
• Allow your program with AT Command
• Call Back Service
• Enable 1 stage dialing ,2 stage dialing
• Backup of CDR
• Support Virtual SIM/Remote SIM Management(1 SIM or MultiSIM)
  • Support USSD Command(SIM Balance,Recharge value)
• Easy Web-based interface management
• 1 year warranty

• 3G Frequecny:
  U Version:2G 850,900,1800,1900MHz,3G 850,2100 MHz
  A Version:2G 850,900,1800,1900MHz,3G 850,1900 MHz
  G Version:2G 850,900,1800,1900MHz,3G 800/850/900/1900/2100HMZ
•
• 4G LTE version (Global)
  LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28
  LTE TDD: B38/B39/B40/B41
  WCDMA: B1/B2/B4/B5/B6/B8/B19
  GSM: B2/B3/B5/B8
•

Optional Choice

Remote SIM Bank

• Connect with PORTech VoIP GSM Gateway via internet
• SIM cards no longer need to be installed in VoIP GSM Gateway anymore
• You can deploy your VoIP GSM Gateway in different locations
• Centralize and supervise all SIMs in one place

SIM Server

• A non blocking switching system between PORTech VoIP GSM Gateway and Remote SIM Bank
• It can assign the calling time for each sheet of the SIM card
• When the time runs out,system will block this GSM port or switch to next unused SIM card

Feature

• Set Talk Time per SIM
• Set GSM Group(Assign several SIMs Per GSM Port)
• Set Day of week
• Set Time Range

Solution suggest
1. If you need the solution for 32 GSM ports,1 SIM per GSM port, you can buy
   MV-3732*1 (option:SBK-128,SS-128)
2. If you need the solution for 32 GSM ports,4 SIMs per GSM port, you can buy
   MV-3732*1,SBK-128*1,SS-128*1
3. If you need the solution for 64 GSM ports,4 SIMs per GSM port, you can buy
   MV-3732*2,SBK-128*2,SS-256

Any GSM solution you neeed, please contact us soon
